GNL Series

Guardian Round LED Series

Versatile decorative round LED luminaire is excellent for walkways, parking structures, common areas. Features die-cast aluminum housings in two finishes and two diffuser options all 1/8″ injection molded polycarbonate and three guard options. All components are completely gasketed. High-frequency motion sensor (completely enclosed) available in either adjustable standby or on/off option. Featuring field adjustable output power (13.5-20.5W) and CCT (3000K-5000K).

Features and Specifications:

Construction:

  • Front trim and back housing are available in 2 standard color choices
  • Finish of the guard is molded throughout
  • Designed for long-term installations
  • Die cast marine grade aluminum housing
  • One-piece injection-molded guard with integral weep hole made from UV-stabilized polycarbonate
  • Tamper-proof TORX™ T-15 pin-in-head stainless steel screws and nylon capture washers provided
  • Diffuser is one piece 0.125” thick injection-molded lens with radial prisms and molded from UV-stabilized polycarbonate in a frost or translucent white option

Listing & Ratings:

  • All electrical components are U.L. listed or recognized
  • All fixtures are U.L. Certified and Union made in the USA
  • Meets Buy America Act (ARRA)
  • Shallow units are ADA compliant

Mounting Options:

  • Surface mount on ceiling or wall

Driver:

  • Universal voltage 120-277V standard
  • 0-10V  dimming to 10% standard

Warranty:

  • 5 years – part replacement only (see our terms & conditions page at www.lamarled.com for details)

Ratings & Certifications:

US-Union-Logo
Voltage-Logo
UL-Logo
RoHS-Logo
CRI-Logo
010VDim-Logo
5YrWarranty-Logo
ColorSelect-Logo
PowerSelect-Logo

GNL Ordering Guide Example:

GNLWATWSOG

GNL A
SeriesColorLens Options
Housing Depth
Faceplate Options
General Options
GNL = Guardian
round LED
W = White
Z = Bronze
Adjustable
CCT and
Output
Field adjustable
CCT
3000k-5000k
Field adjustable
output
2100-3200 Lm
13.5W-20.5W
FR = Frosted ribbed
TW = Translucent white
S = Shallow
D = Deep
CG = Cross guard
EG = Eyelid guard
OG = Open guard
EM = Emergency pack >90 min., >500 lumens
(Deep housing only - Special order Min. Qty's)
HF = High frequency occupancy sensor (on/off)
HFAS = High frequency occupancy sensor
adjustable standby 10, 20, 30 or 50%

Dimensions:

CONSULT YOUR LOCAL ORDINANCES AND BUILDING CODES FOR COMPLIANCE

LAMAR LED, GNL, Outdoor and Vandal Resistant Lighting
Product-Dimension-Temp

LED Lumen/Wattage Chart – 4000K:

PowerFrosted RibbedTranslucent White
13.5W1380Lu832Lu
17W1730Lu1050Lu
20.5W2182Lu1241Lu

High Mode:

 Low (L)Medium (M)High (H)
2’ (1 Board)11.8W - 1370 lu17.3W - 1618 lu26W - 3045 lu
4’ (2 Boards)19.6W - 2716 lu29.4W - 3462 lu50.5W - 5920 lu

Low Mode Wattage:

 Low (L) Medium (M) High (H)
2’ (1 Board)10% - 4.8W
25% - 5.6W
50% - 7.3W
10% - 4.7W
25% - 6.2W
50% - 10.3W
10% - 4.6W
25% - 7.3W
50% - 14.5W
4’ (2 Boards)10% - 4.8W
25% - 6.6W
50% - 11.4W
10% - 4.8W
25% - 8.9W
50% - 16.4W
10% - 7.3W
25% - 14.6W
50% - 27.7W

Sensor Coverage Pattern:

Sensor coverage pattern

Photometrics:

TT(U,H)48M-4: Spacing Criterion (0-180) 1.20 Spacing Criterion (90-270) 1.10

Product-Lumen-Temp

DOWNLOADS

Lumens/Wattage DataPDF IES
1380 Lu/13.5W GNLXAFRXOG-L40GNLXAFRXOG-L40
1730 Lu/17W GNLXAFRXOG-M40GNLXAFRXOG-M40
2182 Lu/20.5W GNLXAFRXOG-H40GNLXAFRXOG-H40
832 Lu/13.5W NLXATWXOG-L40NLXATWXOG-L40
1050 Lu/17W GNLXATWXOG-M40GNLXATWXOG-M40
1241 Lu/20.5W GNLXATWXOG-H40GNLXATWXOG-H40
