DVWL Series
Enclosed Vapor & Dust-Proof
The DVWL is an excellent choice for food processing areas, car washes, cool storage areas and locations subject to the elements due to its vapor and dust proof enclosure. High frequency motion sensors can detect motion through many materials including glass, sheet rock walls, wood doors and the lens of a fixture, enabling the sensor to be hidden from view – consult factory to see if a HF sensor is the right fit for your application.
Features and Specifications:
- Consult factory for motion sensor bilevel control options either totally enclosed within the fixture or external mount.
Construction:
- Housing is molded of one-piece impact resistant fiberglass reinforced polyester; self extinguishing, flame resistant and unaffected by many industrial chemicals
- Internal steel geartray
- Continuous poured gasket is permanently bonded to the upper housing, forming a continuous tight seal with the diffuser
- Frosted acrylic diffuser is 100% impact resistant for maximum transmission
- Stainless steel latches standard
Sensor Options:
- High Frequency motion sensor, internally mounted (on/off)
- High Frequency motion sensor with adjustable standby, internally mounted Infrared motion sensor, externally mounted
Mounting Options:
- Chain, cable or rigid conduit mount
Listing & Ratings:
- LED boards and drivers are U.L. recognized components
- All fixtures are U.L. certified suitable for wet locations and union made
- IP65, IP66, IP67 Certified
- NSF Splash Zone Compliant
- NEMA 4X
- High pressure hose test
Driver:
- Universal voltage 120-277V standard
- Custom driver tuning available for specific lumen requirements
- 0-10V dimming optional
Warranty:
- 5 years – part replacement only (see our terms & conditions page at www.lamarled.com for details)
Ratings & Certifications:
Product Configuration:
LED Lumen/Wattage Chart – 4000K:
| Low (L) | High (H) | |
|---|---|---|
| 4’ (4 Boards High) 4’ (2 Boards Med & Low) | 100W - 13264 lu | 191W - 25384 lu |
Lumen Multipliers:
| 3000K | 1.01 |
|---|---|
| 4000K | 1.05 |
| 5000K | 1.06 |
DOWNLOADS:
| IES | |
|---|---|
| DVLF48HFA30 | DVLF48HFA30 |
Dimensions:
CONSULT YOUR LOCAL ORDINANCES AND BUILDING CODES FOR COMPLIANCE
